ls1021aqds  uboot nand boot

由 shunping lin 于 2017-10-12 提出的问题
最新回复由shunping lin于2017-11-9提供

• 喜欢 • 显示 0 喜欢0
• 评论 • 4

ls1021aqds NAND boot, firstly copy 8KB from NAND flash to IFC SRAM, then CPU execute in this SRAM.   I compiled the uboot and the size of uboot is > 8KB -rw-rw-r-- 1 splin splin 35436 10月 12 14:31 u-boot-spl.pbl
  So I think uboot must copy this code to SDRAM and change to execute in the SDRAM, but I can't find the code in ls1021aqds.c . why?   I confused that the board_init_f() in ls1021aqds.c directly call board_init_r(NULL, 0). the ls1021aqds board don't have enough space in IFC SRAM.   does anyone know the reson?? ?  Thanks!                 The following is board_init_f(),which is called by ENTRY(_main) of crt0.S #ifdef CONFIG_SPL_BUILD
void board_init_f(ulong dummy)
{
struct ccsr_cci400 *cci = (struct ccsr_cci400 *)CONFIG_SYS_CCI400_ADDR;
unsigned int major; #ifdef CONFIG_NAND_BOOT
struct ccsr_gur __iomem *gur = (void *)CONFIG_SYS_FSL_GUTS_ADDR;
u32 porsr1, pinctl; /*
* There is LS1 SoC issue where NOR, FPGA are inaccessible during
* NAND boot because IFC signals > IFC_AD7 are not enabled.
* This workaround changes RCW source to make all signals enabled.
*/
porsr1 = in_be32(&gur->porsr1);
pinctl = ((porsr1 & ~(DCFG_CCSR_PORSR1_RCW_MASK)) |
DCFG_CCSR_PORSR1_RCW_SRC_I2C);
out_be32((unsigned int *)(CONFIG_SYS_DCSR_DCFG_ADDR + DCFG_DCSR_PORCR1),
pinctl);
#endif /* Clear the BSS */
memset(__bss_start, 0, __bss_end - __bss_start); #ifdef CONFIG_FSL_IFC
init_early_memctl_regs();
#endif get_clocks(); #if defined(CONFIG_DEEP_SLEEP)
if (is_warm_boot())
fsl_dp_disable_console();
#endif preloader_console_init(); #ifdef CONFIG_SPL_I2C_SUPPORT
i2c_init_all();
#endif major = get_soc_major_rev();
if (major == SOC_MAJOR_VER_1_0)
out_le32(&cci->ctrl_ord, CCI400_CTRLORD_TERM_BARRIER); dram_init(); /* Allow OCRAM access permission as R/W */
#ifdef CONFIG_LAYERSCAPE_NS_ACCESS
enable_layerscape_ns_access();
#endif board_init_r(NULL, 0);
}
#endif 其他用户没有此问题 可见性：  QorIQ Processing Platforms130 次浏览 最后修改日期：2017-10-12 上午4:54 标签：spl 带有 spl 标记的内容 nand-spl 带有 nand-spl 标记的内容 ls1021aqds 带有 ls1021aqds 标记的内容 nand boot 带有 nand boot 标记的内容 ls1021a-twr 带有 ls1021a-twr 标记的内容 分类： QorIQ LS1 DevicesQorIQ LS2 Devices

• 4 条回复

• Pavel Chubakov 2017-10-13 上午4:51 Look at the following document: https://www.denx.de/wiki/pub/U-Boot/MiniSummitELCE2013/tpl-presentation.pdf   Find information about SPL in u-boot Readme. This file is available in u-boot source folder.
  Have a great day,
  Pavel Chubakov   -----------------------------------------------------------------------------------------------------------------------
  Note: If this post answers your question, please click the Correct Answer button. Thank you!
  ----------------------------------------------------------------------------------------------------------------------- 喜欢 • 显示 0 喜欢0  操作
• Kees Trommel2017-10-17 上午6:49 The SPL U-Boot  (size 15KB) is loaded in the OCRAM (On Chip RAM, size 64KB) of the LS1021A, so there is sufficient space.   Take into account that the SPL U-Boot is loaded into OCRAM using the PBL (Pre-Boot Loader) of the LS1021A. PBL is a list of register addresses and values read by the LS1021A when the LS1021A comes up after an reset (before the U-Boot has started).   When the QoriQ Linux SDK is configured to build a NAND boot an image "u-boot-with-spl-pbl.bin" is generated that includes a PBL coded SPL U-Boot. This image must flashed into first blocks of the NAND device. 喜欢 • 显示 0 喜欢0  操作
  • shunping lin@ Kees Trommel 在 2017-10-27 上午3:50 I see the document(LS1021ARM.pdf) that copy code to IFC SRAM.  喜欢 • 显示 0 喜欢0  操作
  • shunping lin@ Kees Trommel 在 2017-11-9 下午9:10 hello,    Thank you for your help, now I still have a bit confused.      In 4.4.1 Power-on reset sequence of ls1021a document,      15. If the IFC's NAND Flash interface is:
                • configured as the pre-boot initialization source
                OR
                • the boot device target AND not fused as secure boot
                AND
                 • the IFC's NAND Flash interface was NOT previously used as the RCW source,
                   then the reset block informs the IFC to load a boot block from Flash into the
                   internal buffer RAM of the IFC. Once complete, the IFC signals back to the reset
                    block, and the reset block can proceed. Note that if the IFC reports an ECC error,
                   the device reset sequence is halted indefinitely, waiting for a hard reset or PORESET_B.   the document tell that copy boot code to internal RAM of the IFC. when the PBL copy boot code to OCRAM? I don't find any description about that. please help 喜欢 • 显示 0 喜欢0  操作
