CCS+C6678LE开发记录15:多核协作(OpenMP)示例探索

DSP

CCS+C6678LE开发记录15:多核协作(OpenMP)示例探索

2019-07-13 11:42发布生成海报

站内文章 / DSP

16987 0

本文解决了该系列09篇中的一个显著bug，同时也是对多核写作图像处理OMP示例的扩充。本系列10篇：CCS+C6678LE开发记录10:(图像)数据处理与传输框架本文根据...mcsdk_2_01_02_06demosimage_processingopenmpc6678l示例进行修改。原示例是DSP通过HTTP网页服务和PC连接传输数据，修改之后进行了“瘦身”，移除所有webpages，改为UDP数据包方式传送数据。关于UDP传输可以参考这篇文章CCS+C6678LE开发记录03:常规入门HeloWorld 综合之后完成的项目已经上传到GitHub仓库（因为一些原因，暂不公开，如有需要请私信） DSP端(CCSv6) NA PC端(VS2013) NA
测试结果如下
首先连接EVM等待Network初始化完成 ... PC端发送数据

发布了动态图，只能发几张独立的

DSP端发回处理结果数据

原始图片比较大，网络传输消耗了大部分时间。以下是CCS调试输出

[C66xx_0]
Multicore Image Processing using OpenMP

Execute Task_create...
Waiting for the start of the network...
Execute NC_SystemOpen...
Execute CfgNew...
EVM in StaticIP mode at 192.168.2.100
Set IP address of PC to 192.168.2.101
PASS successfully initialized
Ethernet subsystem successfully initialized
Ethernet eventId : 48 and vectId (Interrupt) : 7
Verify_Init: Expected 0 entry count for Queue number = 899, found 498 entries
Registration of the EMAC Successful, waiting for link up ..
IP Addr(1):192.168.2.100
Execute NetworkOpen...
------------------- TASK execution 1 -------------------
ImageSize[Width(1920) * Height(1080)] = 2073600
#WARNING# Exception may occur in the first loop.
ERROR: Data transfer is incomplete (0/2073600)!
------------------- TASK execution 2 -------------------
ImageSize[Width(1920) * Height(1080)] = 2073600
MSP: Send message: SRCIMG_RECEIVED.
MSM: Recv message: SRCIMG_RECEIVED
Image processing...Done.
MSM: Send message: IMGPROC_FINISHED
MSP: Recv message: IMGPROC_FINISHED.
------------------- TASK execution 3 -------------------
ImageSize[Width(2640) * Height(1210)] = 3194400
MSP: Send message: SRCIMG_RECEIVED.
MSM: Recv message: SRCIMG_RECEIVED
Image processing...Done.
MSM: Send message: IMGPROC_FINISHED
MSP: Recv message: IMGPROC_FINISHED.
------------------- TASK execution 4 -------------------
ImageSize[Width(2336) * Height(4160)] = 9717760
MSP: Send message: SRCIMG_RECEIVED.
MSM: Recv message: SRCIMG_RECEIVED
Image processing...Done.
MSM: Send message: IMGPROC_FINISHED
MSP: Recv message: IMGPROC_FINISHED.
------------------- TASK execution 5 -------------------
ImageSize[Width(2336) * Height(4160)] = 9717760
MSP: Send message: SRCIMG_RECEIVED.
MSM: Recv message: SRCIMG_RECEIVED
Image processing...Done.
MSM: Send message: IMGPROC_FINISHED
MSP: Recv message: IMGPROC_FINISHED.

为了进行对比，下面将原始图片及结果图片放在一起（原图已缩小以便于页面浏览体验）
原图1（1920*1080）
