Error Report For : Sheet1.Sch    11-Mar-2014  17:27:30

#1 Error  Duplicate Designators Sheet1.Sch  At (240,300) And Sheet1.Sch  At (210,880)
#2 Error  Duplicate Designators Sheet1.Sch  At (240,300) And Sheet1.Sch  At (1250,461)
#3 Error  Duplicate Designators Sheet1.Sch  At (240,300) And Sheet1.Sch  At (1250,621)
#4 Error  Duplicate Designators Sheet1.Sch  At (240,300) And Sheet1.Sch  At (1250,781)
#5 Error  Duplicate Designators Sheet1.Sch  At (210,880) And Sheet1.Sch  At (1250,461)
#6 Error  Duplicate Designators Sheet1.Sch  At (210,880) And Sheet1.Sch  At (1250,621)
#7 Error  Duplicate Designators Sheet1.Sch  At (210,880) And Sheet1.Sch  At (1250,781)
#8 Error  Duplicate Designators Sheet1.Sch  At (1250,461) And Sheet1.Sch  At (1250,621)
#9 Error  Duplicate Designators Sheet1.Sch  At (1250,461) And Sheet1.Sch  At (1250,781)
#10 Error  Duplicate Designators Sheet1.Sch  At (1250,621) And Sheet1.Sch  At (1250,781)
#11 Error  Multiple Net Identifiers : Sheet1.Sch AVDD1 At (760,820) And Sheet1.Sch AVDD At (760,880)
#12 Warning   Unconnected Power Object On Net B_VCC
    Sheet1.Sch B_VCC

#13 Warning   Unconnected Power Object On Net GND
    Sheet1.Sch GND

#14 Warning   Unconnected Power Object On Net GND
    Sheet1.Sch GND

#15 Warning   Unconnected Input Pin On Net NetQ1_2
   Sheet1.Sch(Q1-2 @680,260)

#17 Error   Floating Input Pins On Net NetQ1_2
Pin Sheet1.Sch(Q1-2 @680,260)

#18 Warning   Unconnected Input Pin On Net NetQ1_3
   Sheet1.Sch(Q1-3 @680,240)

#20 Error   Floating Input Pins On Net NetQ1_3
Pin Sheet1.Sch(Q1-3 @680,240)

#21 Error  Multiple Net Identifiers : Sheet1.Sch VCC At (620,280) And Sheet1.Sch S_VCC At (820,330)
#22 Error  Multiple Net Identifiers : Sheet1.Sch VDP1 At (1090,820) And Sheet1.Sch VDP2 At (1090,660)

End Report 此帖出自小平头技术问答
